System Arm I80H 370, 370x40x220, Aluminum, anodized, aluminum colored
| Quantity | Unit price |
|---|---|
| To 9 |
€414.87*
|
| To 99 |
€352.64*
|
| From 100 |
€229.22*
|
Product number:
11729
EAN:
4054775117292
System Arm I80H 370, 370x40x220, Aluminum, anodized, aluminum colored, Stable pivot arm with a reach of approximately 370 mm and various connection options; pivotable 360°
pre-assembled System arm can be attached lateral, transverse, or on the face of the profile
if attached on the front face, the core hole of the respective profile must be M8 threaded (min. 15 mm deep)
pre-assembled System arm can be attached lateral, transverse, or on the face of the profile
if attached on the front face, the core hole of the respective profile must be M8 threaded (min. 15 mm deep)
| Additional Property: | Friction Torque: 3,0 Nm |
|---|---|
| Colour: | aluminum colored |
| Compatibility: | Type I |
| EU responsible person: | Inprocraft GmbH, Handwerkstr. 1, 91166 Georgensgmünd, Germany; info@inprocraft.com |
| Grid dimension: | 40 mm |
| Location - Mounting: | screw-on |
| Manufacturer information: | Inprocraft GmbH, Handwerkstr. 1, 91166 Georgensgmünd, Germany; info@inprocraft.com |
| Material: | Aluminium |
| Max. load (in kg): | 17 |
| Selection Number: | 6FG80NH370S80N08 |
| Setinfo: | complete |
| Size (in mm): | 370x40x220 |
| Slot: | 8 |
| Surface: | anodized |
| Weight (in g): | 3350.3 |
